Cleaning Systems
Walking-Beam-Type Washers
These are through-feed, inline multi-station washers that have an internal component lift-and-carry mechanism that enables fully automatic operation, high productivity and high-quality special purpose cleaning
- Layout with five to fifteen stations depending on cleaning requirements
- Ability to integrate high-pressure deburring, vacuum drying and injection flood
- Component rotation at individual cleaning stations for enhanced cleaning results
- Manual / gantry or other type of automatic loading
- Washing: high pressure deburr and cleaning; injection flood wash; seal and flush; spray wash (single-stage or multi-stage washing with superclean liquid in the final stage)
- Drying: vacuum drying; compressed airblow; ambient / hot airblow; component rotation
- Part Types: cylinder block; cylinder head; transmission housings; crankshafts; other machined parts with intricate geometries
- Cleaning Application:
- Targeted final cleaning of critical areas such as oil or fuel galleries and water jackets after machining
- Intermediate cleaning to meet input condition requirements of downstream process
- Output Cleanliness: suitable for meeting most stringent cleanliness norms
- Throughput: high (minimum 52s)
- High productivity
- Superior cleaning results
- Supports fully unmanned operation
